Features
Both models are designed for BOD determination.
• PID controller with auto-tuning to ensure rapid heating and minimum temperature fluctuation and overshoot.
• Push-button operation and LED screen displays both the set and actual temperature values digitally to ±0.1°C
• Locking function of set temperature values.
• Auto-diagnostic system integrated in the controller ensures rapid identification and correction if any fault does occur.
• Off-set function for calibration use. Important for ISO/Calibration requirements.
• Back-up system memory protects the set point values in case of power failure.
• Environment-friendly CFC-free refrigeration system.
• Dual-pane heated glass door provides for full-view test samples (for model Cool-300 only)
• Manufactured by a factory certified to ISO 9001 : 2008
• Type tested to MS IEC 61010-1 : 2006 standard electrical safety test
Applications
• Microbiological testing
• BOD tests
• Tissue culture
• Milk testing
• Shelf-life testing
• Product storage requirements
• Plant growth / germination studies
| Model | COOL-300 |
|---|---|
| Type | Floor-standing, single-door |
| Cabinet Construction | Powder-coated mild steel exterior and interior |
| Capacity | 300 litres |
| Temperature | 5 to 60°C |
| Controller | PID controller |
| Temperature accuracy | ±0.1°C |
| Temperature setting and display | Digital, display up to 0.1°C |
| Thermo sensor | PT-100 |
| Air circulation | Aided by circulation fan |
| Heater | 800 watt |
| Compressor | Hermetic-seal type |
| Defrost | With auto-defrost and time delay protector |
| Refrigerant | R134a, CFC free |
| Safety features | Over-temperature protection, circuit breaker, high-low pressure switches |
| Door type | Dual-pane heated glass door with fan switch which stops circulation fan when door is opened. Supplied with door lock as standard. |
| Viewing lamp | Included |
| No. of shelves supplied | 4 units |
| Shelf dimensions (mm) | 480W x 450D x 10H |
| Interior dimensions (mm) | 500W x 595D x 1105H |
| Exterior dimensions (mm) | 587W x 720D x 1720H |
| Electrical | 220-240 VAC, 50Hz, 6.4A |
| Weight | 88 kg |
