Features
• Heating element lies behind a panel at the back of the chamber – eliminated the risk of scorching samples placed on the chamber floor.
• Special designed horizontal guided airflow ensures uniform heat distribution throughout the chamber.
• Independent safety thermostat prevents temperature overshoot.
• Microprocessor – PID digital temperature controller ensure set temperature is achieved quickly and accurately.
• LED dual -display screen displays both the set and actual temperature to 0.1°C
• Over-temperature shut off feature is factory set at 75°C
• Back -up system memory protects the set point values in case of power failure.
• Off-set function for calibration use. Important for ISO/Calibration requirement.
• Set temperature accurately and easily with push buttons.
• Shelves are adjustable over the full height of the chamber on half-inch centers and can be slide out for easy clearing.
• Stainless steel interior and powder coated mild steel exterior.
• Supplied with two stainless shelves and two meter length power cord with grounded plug.
• Manufactured by a factory certified to ISO 9001 : 2016
• Type tested to MS IEC 61010-1 : 2006 standard electrical safety test
| Model | AMBI-50 |
|---|---|
| Type | Bench-top |
| Cabinet Construction | Powder coated mild steel exterior and stainless steel interior chamber |
| Capacity | 100 litres |
| Temperature | Ambient +5 to 60°C |
| Temperature control | PID controller |
| Accuracy | ±0.1°C |
| Sensor | PT-100 |
| Setting and display | Digital display to 0.1°C |
| Safety device | Over temperature thermostat |
| Circulation | Aided by built-in fan |
| Shelves supplied | 2 stainless steel shelves |
| Shelves size (mm) | 390D x 470W x 10H |
| Exterior dimensions (mm) | 625D x 675W x 825H |
| Interior dimension (mm) | 430D x 475Wx 475H |
| Electrical loading of heater | 300 watt |
| Electrical | 240 VAC,50Hz, 1.3A |
| Weight | 44.5 kg |
