Features and benefits
• CFC free refrigeration – environmental friendly
• Frost – free operation – Relief you of the trouble of defrosting the freezer
• Oversized cooling system – ensure speedy temperature recovery
• Built-in overload protection for compressor – ensures lasting operation
• Lock provided as standard – secure against unauthorized access
• Door with fan switch stops circulation fan when door is open-reduces temperature fluctuations
• Large powder coated mild steel cabinet – provides extra storage space and durable usage
• Temperature control – factory set at -20°C (adjustable from -5°C to -20°C)
• Digital thermometer – temperature is display numerically
• High density polyurethane foam insulation – reduces operational costs and protects unit from ambient temperature fluctuations
• Automatic condensate removal – eliminates the need for drain lines
• Hermetically sealed compressor – sound insulated to reduce noise
• Forced air circulation – keeps temperature consistent at all levels
• Double – pane glass door – provides for full – view and eliminated condensation
• Runs on demand refrigeration design – reduces power consumption
• Self closing door – ensure against energy loss
• Full – length adjustable shelves – for easy loading and unloading of stored products
• Caster wheel with locking brakes – for easy transportation and safety at site when placed in position
| MODEL | FREEZE-500 |
|---|---|
| Type | Frost free freezer |
| Cabinet construction | Inner wall and outer casing of mild steel with stoves powder paint finish |
| Cabinet insulation | CFC-free polyurethane, foam-in place insulation |
| Temperature working range | -5°C to -20°C |
| Controller | Digital microprocessor controller with defog, lock and off-set functions |
| Temperature setting & display | Digital display to 1°C, adjustable in 1°C increment |
| Thermo sensor | PTC |
| Air circulation | Aided by circulation fan |
| Safety devices | Over temperature protection, built-in overload protection for compressor, ELCB |
| Refrigerators | Hermetic seal type |
| Refrigerant | 404A CFC FREE |
| Cooling capacity at -20°C | 2632 BTU/hr |
| Defrost | Auto defrost by built-in heater |
| Capacity | 500 litres |
| Shelves | 5 pcs |
| Chamber dimensions (mm) | 520W x 685D x 1270H |
| Overall dimensions (mm) | 640W x 825D x 2070H |
| Power source | 240VAC, 50Hz, 7.5A |
| Weight | 130 kg |
