System Features

  • LCD Temperature Control Systems
    • Button-type control panel is easy to operate, the temperature and alarm settings can be adjust on the panel.
  • LBA Forming Technology
    • The world’s leading fourth generation foaming agent more uniform density, better insulation, more energy-saving.
    • More reasonable foaming layer design, larger interior storage space.
  • Micro-channel condenser
    • Powerful heat dissipation for condenser, heat exchange capacity increase by more than 20% than common copper tube fin condenser.
    • Excellent compressor overheating protection, effectively improve the service life of core parts.
  • Three-dimensional seal
    • The unique three-dimensional seal, through the double-layer door seal and the multi-layer airbag sealing design, can effectively reduce the leakage of cold air and achieve best thermal insulation performance.

ITEMMODELMC-40L106
Product structure dataTemperature Range-20°C ~ -40°C
Fridge Storage Volume (L)106L
External MaterialHigh quality coated steel
Internal MaterialHigh quality coated steel
Product Dimensions (mm) (W x D x H)595 x 615 x 812
Interior Dimensions (mm) (W x D x H)455 x 460 x 595
Net/Gross Weight (kg)43/48
Technical dataCooling TypeDirect cooling
Defrost typeManual
Climate ClassN
Rated Voltage/Frequency(V/Hz)220 ~ 240V / 50Hz
Rated Power (W)230
Rated Current (A)1.5
RefrigerantR290
ControlControllerMicroprocessor
DisplayLCD display
Product PerformanceTemperature Accuracy0.1°C
Temperature uniformity/°C≤ 3°C
AlarmsPower Failure AlarmY
Sensor Failure AlarmY
Environment Temperature AlarmY
Door ajar AlarmY
High Temperature AlarmY
Low Temperature AlarmY
Remote AlarmY
AccessoriesUSBY
Anti-condensation DoorY
Backup BatteryY
HandleGrip (Reverse door)
Cable Port1/25mm
Castors/typeFeet
