Features
• Microprocessor – PID controller makes it easy to achieve and maintain the exact temperature desired.
• Temperature can be set easily and accurately with push-buttons.
• LED dual-display screen displays both the set and actual temperatures to ±1℃.
• Back-up system memory protects the set point values in case of power failure.
• Heavy duty hot air fan ensures long lasting operations.
• Cold air intake port and adjustable exhaust port ensure optimum performance in various applications.
• Constructed of stainless steel interior and powder-coated mild steel exterior.
• Double-wall design with fiberglass insulation for excellent heat retention.
• Stainless steel shelves adjustable over the full height in 1/2″ increment.
• Side-swing doors with locks (for FAC-800 only).
• Off-set function for calibration use. Important for ISO/Calibration requirements.
• Supplied with four stainless steel shelves and a two meter power cord with grounded plug.
• Manufactured by a factory certified to ISO 9001 : 2016
• Type Tested to MS IEC 61010-1 : 2006 Standard Electrical Safety Test
Applications
• General drying
• Heat treatment of polymers
• Thermal testing
• Baking
• Sterilizing
• Conditioning
• Firing of coatings
| Model | FAC-800 |
|---|---|
| Type | Double-door |
| Capacity | 770 litres |
| Cabinet construction | Coated mild steel exterior and full stainless steel interior chamber |
| Temperature range | Ambient +5℃ to 220°C |
| Temperature control | PID controller |
| Temperature setting and display | Digital,display up to 0.1 °C |
| Safety device | Independent over-temperature protection & Fan-Overload Protection |
| No. of shelves supplied | 4 units stainless steel shelves |
| Shelf dimensions (mm) | 1060W x 580D x 20H |
| Interior dimensions (mm) | 1080W x 600D x 1190H |
| Exterior dimensions (mm) | 1450W x 780D x 1570H |
| Heater power | 6 kW |
| Heat up time to 150°C | 15 min |
| Recovery time, oven at 150°C (door open for 1 min) | 5 min |
| Electrical | 415 VAC, 50Hz, 34W, 20A |
| Weight | 185 kg |
